KPY3 displacement measurement Click:


KPY3
Output signal mode
A.Resistance: 1K,2K, 5K,
B.Current: 4-20mA
C.Power: 5V,10V,12V,24V
D.Related digital indicator: up-limit and bottom-limit setting function (relay output, analogue, RS232/485 interface)
