LPS-14,14S
Click：
Apply for travel controlling, the detection of electric actuator institutions etc. Stroke range: 0-14mm
Electrical Specifications
| Active Electrical Travel | 14mm | |
| Total resistance | 1.2KΩ | 2KΩ |
| Total resistance error | ±20% | |
| Independent linearity | ±1%（0.5%） | |
| 额定功率 | 1W/70° | |
| Output smooth | ±0.1% | |
| Insulation resistance | DC500V 100MΩ以上 | |
| Dielectric strength | AC500V 1 minute | |
| Mechanical travel | 16mm |
| Sliding force | 29*10﹣²N |
| Weight | About 70g |
| Operating temperature range | -40～100℃ |
| Vibration | 98m/s²(10G)500Hz |
| Operating speed | 490m/S²(50G)11ms |
| Working life | 10×106 cycles |
